MAX A2-150.4

MAX A2-150.4

Feed your system with the raw power from a MAX A2 amplifier! We welcome you to the next level with oversized capacitors and MOSFET transistors on a solid, double-sided PCB!

SKU: MAXA21504

Description

GET READY FOR RAW POWER

Feed your system with the raw power from a MAX A2 amplifier! We welcome you to the next level with oversized capacitors and MOSFET transistors on a solid, double-sided PCB!

DUAL DIFFERENTIAL INPUT

The MAX A2 amplifiers are equipped with 2DP™, a state-of-the-art pre-amplifier with dual differential input circuits, because just like you we don’t like distortion. The 2DP™ will keep the unwanted noise at a minimum without compromising on the most important thing- awesome power.

HIGH QUALITY HIGH PASS

With great power comes the need for great precision crossovers. The MAX A2 have high quality 12dB high-pass filters and combined low- and band-pass filters, and to add even more control these CLASS AB amps come with a symmetrical push-pull power stage and AAB (Active Auto Bias)!

(And just to be sure, we have installed advanced safety systems including soft start and shutdown functions to protect your system against voltage spikes and drops, overload, overheating and short circuiting).

Additional information

Component

Amplifier

Channels

Four

Input mode

Mono / 2Ch, Mono / 2Ch / 4Ch

Power RMS (2 Ohm)

4x230W

Power RMS (4 Ohm)

4x150W

Bridged Power RMS (4 Ohm)

2x460W

Freq. response

10-45.000 Hz

Low Pass Filter

30-4.000 Hz

High Pass Filter

10-4.000 Hz

S/N Ratio (A-weighted)

>102dB

Bass EQ

0-12dB @45Hz

Crossover Slope

12dB

Power Voltage

10-16V

REM Voltage

10-16V

Input Sensitivity

0.5-6V

Input Impedance

10K Ohm

T.H.D

<0.05%

Power Fuse

3x35A

Damping Factor

>150

High Level Input

Yes

RCA Line Out

Yes

Product Manual MAX A2-100.2

Download
