MAX S2-15D1/D2

MAX S2-15D1/D2

If you have this in your hand, you have taken the next step. You’ve entered a world of NO COMPROMISES with a subwoofer that will take your car audio to a whole new level!

MAXS210D1D2-1-1-1

Description

If you have this in your hand, you have taken the next step. You’ve entered a world of NO COMPROMISES with a subwoofer that will take your car audio to a whole new level. So get out there and shake the foundation to its core! Show them that true dedication comes from the inside of your trunk and that “good enough” never will be enough.

THIS IS WHAT REAL BASS FEELS LIKE

A MAX subwoofer is designed to test the limits and match your dedication in performance and style. To be able to withstand the extreme conditions you surely will put this subwoofer through, the cone is made of non-pressed paper with Mica minerals that excellently balances awesome power, weight and musicality. To handle all of this beautiful bass, we’ve implemented a T-bone basket that holds vibrations at bay and adds extra stability for the larger models (12” & 15”).

TRULY NEXT LEVEL

The dust cap is made of IMPP, an idea we borrowed from the MAD S2 series. But since this is MAX, we took it one step further and reinforced it with fibers. It’ll handle everything you throw at it! The impressive high roll ribbon foam suspension gives you even more awesome cone movement. This cone is simply made to move! The 3-inch dual black coated BASV voice coil wire is made of PCW (Pure Copper Wire) and will make sure the subwoofer handles both an insane amount of power and heat. To give you an unmatched connection, we’ve added four 6mm² pure OFC copper (direct tinsel terminated) speaker cables instead of old fashioned terminals.

IMPRESSIVE IN EVERY SINGLE WAY

The MAX S2 series will make jaws drop. We show our dedication to the craft of bass with triple stacked HQ ferrite magnets to achieve a truly mind-blowing amount of motor in the subwoofer. We’ve added a Dual Nomex spider with orange mesh technology and dual stitching for extra durability, to make sure that the last thing standing will be your sound system. Is this enough for you? We doubt it. To add even more durability and flexibility we’ve added a woven web to the spider, for extra strength and style!

COOL UNDER PRESSURE

The MAX S2 will show everyone that you have reached the next level, the MAX level. Having a subwoofer perform at this level demands extremely good ventilation. Only the best and beyond is good enough! We solved the cooling in two different ways. The material in the top/back plate is thicker for optimal heat conduction, and the implemented DVS2 (Dual Ventilation System) creates incredible heat dissipation while also reducing distortion.

Additional information

Series

MAX

Component

Subwoofer

Size

15 inch

Nominal Impedance

1+1 Ohm, 2+2 Ohm

Power RMS

2500W

Power MAX

5000W

Freq. response

20-200Hz

Voice Coil

Dual 3" 4-layer copper wire

Cone

Reinforced Mica Pulp Cone

Dustcap

A-Star 3D IMPP

Basket

HD Aluminium

Magnet

3x108oz HQ Ferrite

Suspension

High roll ribbon foam (dual stitch)

Product Manual MAX S2-15D1/D2

Download

User manual for MAX S2(S2-10D1/D2, S2-12D1/D2 & S2-15D1/D2)
